LCN 4031 Series Heavy Duty Door Closer - Aluminum, Grade 1
LCN Heavy Duty Aluminum Door Closer
The LCN 4031 Series Heavy Duty Door Closer is designed for seamless operation in both interior and exterior settings. Engineered with hydraulic power and an aluminum finish, it supports a wide range of door sizes with its adjustable spring force, making it versatile for various mounting types.
Key Features:
- Versatile Mounting: Configure as standard, top frame, or parallel closer to match door swing and preference.
- Heavy Duty Construction: Made with durable cast iron and a robust aluminum finish for maximum longevity.
- Smooth Operation: Features hydraulic energy source to ensure consistent, reliable door movement up to 180°.
- Universal Application: Suitable for both interior and exterior doors, compatible with ADA requirements.
- Complete Installation: Includes all necessary hardware and metal cover for hassle-free setup.
Specifications Table:
| Specification | Details |
|---|---|
| Manufacturer Part Number | 4031-RW/PA AL |
| Brand | LCN |
| Closer Mounting Type | Parallel |
| Closer Series | 4031 |
| Closer Stop Type | Standard |
| Closer Type | Non-Hold Open |
| Color | Gray |
| Display Qty | 1 |
| Display Sell UOM | EA |
| Max Door Opening Angle | 180 ° |
| Finish | Aluminum |
| Housing Depth | 2-7/8 in |
| Housing Height | 2-7/8 in |
| Energy Source | Hydraulic |
| Includes | Metal Cover |
| Includes Hardware | Hardware Included |
| Door Width Campatibility | 47-124/125 in |
| Location Use | Interior/Exterior |
| Standards | BAA |
| UL Fire Rating | UL10C |
| Spring Type | Adjustable |
| Height Between Mounting Holes | 1 in |
| Spring Size - Minimum | 1 |
| Material | Cast Iron |
| Exterior Door Width - Maximum | 36 in |
| Product Type | Door Closer |
| Projection | 1-3/4 in |
| Spring Size | 4 |
| Hand Orientation | Non-Handed |
| Housing Length | 10-3/8 in |
| Operation Style | Manual |
| Performance Duty Rating | 1 |
| Length Between Mounting Holes | 1-23/32 in |
| Ligature Resistance | Not Ligature-Resistant |
| ADA Compliant | Yes |
| Performance Rating | Grade 1 - Heavy Duty |
| Finish C | Aluminum Painted ; Cast Iron ; Gray |
Frequently Asked Questions (FAQ):
Q: What types of doors is this closer compatible with?
A: The LCN 4031 Series is compatible with both interior and exterior doors and can handle a wide range of door widths between 47 inches to 124 inches.
Q: How is the door closer installed?
A: The door closer can be mounted in parallel, top frame, or standard installation modes, depending on your door swing preferences. It comes with all necessary hardware for installation.
Q: Is this door closer ADA compliant?
A: Yes, the LCN 4031 Series door closer is ADA compliant.
Q: What is the lifespan of this door closer in high-traffic areas?
A: This door closer has a Grade 1 heavy-duty performance rating, designed to withstand high usage in commercial settings, offering durability and reliability over extended periods.
Q: Does the door closer provide variable closing speeds?
A: Yes, the adjustable spring mechanism allows you to set the closing speed to meet your needs, providing flexible control during operation.
Elevate Your Space with Seamless Door Functionality
Step into a realm where functionality meets sophistication with the LCN 4031 Door Closer. Its aluminum finish offers a sleek yet durable touch. Crafted to seamlessly integrate into any design aesthetic, this door closer ensures smooth transitions and understated elegance in every space. Whether in a bustling office or a serene home, this essential piece enhances the architectural narrative, elevating entryways with its reliable performance and timeless appeal.
Upgrade your doors with the LCN 4031 Series for the ultimate in durable, design-friendly closure solutions.
