Automation Systems Interconnect 20 Amp, 480-Volt AC, 3 Pole, DIN Rail Mount Miniature Circuit Breaker, Trip Curve: C, UL1077
20 Amp 3-Pole DIN Rail Miniature Circuit Breaker
The Automation Systems Interconnect 20 Amp, 3-Pole Miniature Circuit Breaker is designed for optimal performance in 480-Volt AC circuits. This compact yet powerful breaker features a C trip curve, ideal for handling typical inductive loads while offering reliable overload and short circuit protection. It seamlessly integrates onto DIN rails with its screw clamp MCB terminations, making it an essential component for modern electrical systems.
Key Features:
- C Trip Curve: Designed for optimal performance with inductive loads.
- Visual LED Indication: Easily identifies when the breaker has been tripped.
- 10kA Interrupt Capacity: Superior protection from overloads and short circuits.
- DIN Rail Mount: Streamlined installation with secure screw clamp terminations.
- Certifications: Meets UL1077, TUV, and CE standards for reliability.
Specifications Table:
| Specification | Details |
|---|---|
| AIC Rating | 10 |
| Breaker Type | Standard |
| Connection Type | Non-Neutral |
| Interruption Type | Standard Trip |
| Maximum Amperage (A) | 40 A |
| Mounting Type | Din Rail |
| Number of Poles | Triple |
| Number of Spaces | 1 |
| Pack Size | 1 |
| Product Weight (lb.) | .9 lb |
| Series Type | Not Specified |
| Trip Unit | No Trip Unit |
| Voltage (V) | 480 V |
| Certifications and Listings | TUV Listed,UL Listed |
| Manufacturer Warranty | 1 Year Limited Warranty |
| Product Depth (in.) | 2.05 in |
| Product Height (in.) | 2.91 in |
| Product Width (in.) | 3.19 in |
Frequently Asked Questions (FAQ):
Q: What type of loads is this circuit breaker suitable for?
A: This circuit breaker is ideal for handling inductive loads due to its C trip curve.
Q: How do I know if the breaker has tripped?
A: The breaker features a visual LED indicator that lights up when tripped.
Q: Can this breaker be used in residential applications?
A: Yes, while it is designed for supplemental protection in commercial settings, it can also be used in residential installations that match its specifications.
Q: Is this breaker compliant with any safety or environmental standards?
A: Yes, this breaker is RoHS compliant and meets multiple standards including UL1077, TUV, and CE.
Q: What is the warranty on this product?
A: The product comes with a 1-year limited warranty for peace of mind.
Elevate Electrical Efficiency with Sleek Functionality
The Automation Systems Interconnect circuit breaker excels in delivering both form and function. Its slim DIN rail design allows for seamless integration into any electrical panel, optimizing the use of space while ensuring robust protection against overloads. Imagine the confidence of a flawlessly safe environment for your home's electrical system, where sleek technology doesn't just perform—it transforms the heart of your home's energy source into a synchronization of style and safety. Truly indispensable for the modern, luxury-centric abode.
Upgrade your electrical system's protection by adding the 20 Amp DIN Rail Circuit Breaker to your project today.
